TSC TTP-247 Service Manual

4
Internal font
 8 alpha-numeric bitmap fonts
 One Monotype Imaging® CG Triumvirate Bold
Condensed scalable font
Code Page
 Codepage 437 (English - US)
 Codepage 850 (Latin 1)
 Codepage 852 (Latin 2)
 Codepage 860 (Portuguese)
 Codepage 863 (French Canadian)
 Codepage 865 (Nordic)
 Codepage 857 (Turkish)
 Codepage 861 (Iceland)
 Codepage 1250 (Latin 2)
 Codepage 1251 (Cyrillic)
 Codepage 1252 (Latin 1)
 Codepage 1253 (Greek)
 Codepage 1254 (Turkish)
 Codepage 1257 (Baltic)
 Codepage 1258 (Vietnam)
 ISO-8859-1: Latin-1 (Western European)
 ISO-8859-2: Latin-2 (Central European)
 ISO-8859-3: Latin-3 (South European)
 ISO-8859-4: Latin-4 (North European)
 ISO-8859-5: Cyrillic
 ISO-8859-7: Greek
 ISO-8859-9: Turkish
 ISO-8859-10: Nordic
 ISO-8859-15: Latin9
Bar code
1D bar code
Code 39, Code 93, Code128UCC, Code128 subset A,
B, C, Codabar, Interleave 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits
add-on, MSI, PLESSEY, POSTNET, China POST
2D bar code
PDF-417, Maxicode, DataMatrix, QR code
Font & barcode rotation
0, 90, 180,270 degree
Command set
TSPL-EZ

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
