TSC TTP-247 Service Manual

5
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type
Outside wound
Media width
20~112mm (0.78" ~ 4.4")
Media thickness
0.06~0.19 mm (2.3~7.4 mil), max. 150g/m
2
Media core diameter
25.4~76.2 mm (1”~3”)
Label length
Min. 10 mm (0.4”)
Label length (peeler mode)
25.4~152.4 mm (1”~6”)
Label length (cutter mode)
25.4~2286 mm (1”~90”)
25.4~1016mm (1”~40”)
Gap height
Min. 2 mm
Black mark height
Min. 2 mm
Black mark width
Min. 8 mm (0.31”)
Printout bias
Vertical: 1 mm max.
Horizontal: 1 mm max.
Environment condition
Operation: 5~40
o
C, 25~85% non-condensing
Storage: -40~60
o
C, 10~90% non-condensing
Safety regulation
FCC Class B, CE Class B, C-Tick Class B, UL, CUL,
TÜ V/GS, CCC
Accessories
 BarTender UltraLite CD disk
 Quick start guide
 USB cable
 External universal switching power supply
 Power Cord
 Label Spindle, fixing tab x2, 1.5” core adapter x2
 Ribbon spindle x2
 Ribbon rewind spindle paper core
Reliability
 TPH: 1 million inches or 12 months, which comes
first since delivery from TSC (service part)
 Platen: 50 km (service part)
Factory option
 Real time clock

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
