TSC TTP-247 Service Manual

6
Dealer option
 Peel off module assembly.
 Guillotine cutter
Full cut:
Paper thickness: 0.06~ 0.19mm, 500,000 cuts
Partial cut:
Paper thickness: 0.06~0.12mm, 500,000 cuts
Paper thickness: 0.19mm 200,000 cuts
 Main board integrated with internal Ethernet
 Internal Ethernet print server module
User option
 KP-200
 KU-007 plus
 External Ethernet print server
 External wireless (802.11b/g) print server
 External roll mount, media OD. 214 mm (8.4”) with 3”
core label spindle
 Contact CCD contact scanner
 Long range linear image bar code scanner
1.2.2. Printer (TTP-247 / TTP-345)
Item
Printer model
TTP-247
TTP-345
Resolution
203 DPI
300 DPI
Printing method
Thermal Transfer & Direct Thermal
Print speed
2, 3, 4, 5, 6, 7 ips.
2, 3 ips for peeler mode
2, 3, 4, 5 ips
2 ips for peeler mode
Max. print width
108 mm (4.25”)
106 mm (4.17”)
Max. print length
2286 mm (90”)
1016 mm (40”)
Enclosure
Double-walled plastic
Physical dimension
314mm (L) x 213mm (W) x 188mm (H)
Ribbon capacity
300 meter, 1” core
Label roll capacity
5” OD

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
