TSC TTP-247 Service Manual

12
Printer Initialization
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns green after 5 amber
blinks. (Any green will do during the 5 blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks) 
green (5 blinks)  green/amber (5 blinks) 
red/amber (5 blinks)  solid green
Note:
Always do gap/black mark sensor calibration after
printer initialization.
Force Black Mark
Sensor Calibration
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns green/amber after 5
green blinks. (Any green/amber will do during the 5
blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks) 
green (5 blinks)  green/amber (5 blinks) 
red/amber (5 blinks)  solid green
Force Gap Sensor
Calibration
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns red/amber after 5
green/amber blinks. (Any red/amber will do during the 5
blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks) 
green (5 blinks)  green/amber (5 blinks) 
red/amber (5 blinks)  solid green

TSC TTP-247 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	4.09" (104 mm)
Processor	32-bit RISC CPU
Weight	2.5 kg
Max Print Speed	7 ips
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0, Serial
Ribbon Capacity	300 meters
Label Width	1" (25.4 mm) ~ 4.33" (110 mm)
Label Thickness	0.06 mm ~ 0.19 mm
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Operating Humidity	25% to 85%, non-condensing
Certifications	CE, FCC, UL, CCC
