SPECIFICATIONS AND INSTALLATION
7
Optional Installation Items
Oven Restraint Kit (P/N: TC3-0242 KIT)
The oven restraint kit is an optional device that
prevents the oven from moving forward during use
and cleaning. It will not prevent the oven from fall-
ing off a countertop if the oven is pulled off or the
legs are allowed to slide off the edge. Call
1-800-90TURBO or your Authorized Distributor
for more information.
Oven Cart
Construction
£
Available heights: 18” (457 mm) or
24” (610 mm)
£
304 stainless steel
£
14-gauge 304 stainless steel top
£
16-gauge 304 solid stainless steel shelf
£
Four 6” (152 mm) high polyurethane tired
casters, front two with safety locking brakes;
bolt-on to stainless steel leg
Standard Features
£
Reinforcement: Welded gusset plates between
legs and top to ensure rigidity/eliminate stand
racking
£
Frame: Fully welded 1.5” x 1.5” (38 mm x 38
mm) square stainless steel tube
£
Easy to assemble
Call 1-800-90TURBO or your Authorized
Distributor for more information.
18" (457 mm) Oven Cart Dimensions
Height 18" (457 mm)
with single oven 39.4" (1001 mm)
with stacked ovens*
top unit without legs 56.8" (1443 mm)
top unit with legs 60.8" (1544 mm)
Width 27.8" (706 mm)
with single oven 27.8" (706 mm)
with stacked ovens* 27.8" (706 mm)
Depth 26.625" (676 mm)
with single oven 31.7" (805 mm)
with stacked ovens* 31.7" (805 mm)
24" (610 mm) Oven Cart Dimensions
Height 24" (610 mm)
with single oven 45.4" (1153 mm)
with stacked ovens*
top unit without legs 62.8" (1595 mm)
top unit with legs 66.8" (1697 mm)
Width 27.8" (706 mm)
with single oven 27.8" (706 mm)
with stacked ovens* 27.8" (706 mm)
Depth 26.625" (676 mm)
with single oven 31.7" (805 mm)
with stacked ovens* 31.7" (805 mm)
*Requires Stacking Bracket.
Assembly instructions are included with the cart.
If additional help is needed, call 1-800-90TURBO
or your Authorized Distributor.
Figure 6: 24” (610 mm) Oven Cart with Oven(s)
NOTE: If using 18”
(457 mm) cart, subtract
6” (152 mm) from all
measurements.
