VacDip2 – Vacuum value in the remaining pulses
This value defines the vacuum in the remaining pulses in the pre-vacuum stage (not just
pulse no. 2)
Entry code
11
Resolution
1kPa (0.1 psi)
Minimum value
1kPa (0.15 psia)
Maximum value
75kPa (10.8 psia)
VacTime1 – Waiting time in the first pulse
In the pre-vacuum stage, in the first pulse after arriving at VacDip1, there is a waiting
time known as VacTime1 (in seconds).
This delay occurs so that air removal and vacuuming can continue.
Entry code
11
Resolution
1 second
Minimum value
3 seconds
Maximum value
1800 seconds (30
minutes)
VacTime2 – Waiting time for the remaining pulses
For the remaining pulses (following pulse no.1) in the pre-vacuum stage, after arriving at
the VacDip2 stage there is a time delay known as VacTime2 (in seconds).
Entry code
11
Resolution
1 second
Minimum value
3 seconds
Maximum value
1800 seconds (30
minutes)
WtrTime – Time for entering the water into the generator after the electrode
touches the water.
This value defines the time (in seconds) during which the water pump continues to work
and enter water to the steam generator after the upper electrode touches water.
This is done to prevent a situation where right after the electrode touches water, the
pump immediately stops operating.
Entry code
11
Minimum value
Ø second
Maximum value
90 seconds
