15. VALVES NUMBERING
The valves in the drawing and the manual are numbered according to their
function. The following list includes all the valve numbers that are in use in
Tuttnauer
0. FUNCTION
01. Change-over : steam / electricity
02. Locking door cylinder (front door)
03. Locking door cylinder (Rear door)
1. FEED WATER
11. Feed water – cool jacket
12. Feed water – cool heat exchanger
13. Feed water – cool fast exhaust
14. Feed water – to reservoir
15. feed water – to vacuum pump
16. Water outlet
17. Shut
18. Feed water – to ejector
2.
MINERAL FREE
WATER
21. Mineral free water - inlet
22. Detergent
23. To spry
24. Recycling inlet
25. Recycling outlet
3.
COMPRESSED
AIR
31. Air inlet
32. Air inlet - to chamber
33. To splash cooling pipe
34 – 1. To door 1 seal
34 – 2. To door 2 seal
38 – 1. Open door 1
38 – 2. Open door 2
39 – 1. Close door 1
39 – 2. Close door 2
4. AIR
41. Air release N.C.
42. Air release N.O.
43. Filtered air - inlet
44. Air Inlet
45. Aeration
5. VACUUM
51. Vacuum - break
52. Vacuum - to pump
53.1 Vacuum - from door 1 seal
53-2. Vacuum - from door 2 seal
