Chapter 13. Groups of parameters
13. Groups of parameters
13.1. Inverter status parameters – group 0
This group contains „read only” inverter status parameters with access without any password.
Param.
No.
Name Unit
Access
level
Description
00.01 Produced energy kWh O Total produced energy
00.02 Run time
h
O Total working time
00.03 Grid power L1
W
O Active power from the grid side in phase L1
1)
00.04 Grid power L2 Active power from the grid side in phase L2
1)
00.05 Grid power L3 Active power from the grid side in phase L3
1)
00.06 Grid frequency Hz O Electrical grid frequency
00.09 Grid volt. L1 V O L1 phase grid voltage
00.10 Grid volt. L2 V O L2 phase grid voltage
00.11 Grid volt. L3 V O L3 phase grid voltage
00.12 Grid curr. L1 A O L1 phase grid current
00.13 Grid curr. L2 A O L2 phase grid current
00.14 Grid curr. L3 A O L3 phase grid current
00.15 Grid r.power L1 var O Output reactive instantaneous power L1
1)
00.16 Grid r.power L2 var O Output reactive instantaneous power L2
1)
00.17 Grid r.power L3 var O Output reactive instantaneous power L3
1)
00.18 Grid power sum W O Total active power from the grid side
(sum of phases L1, L2, L3)
1)
00.19 Grid r.power sum var O Total reactive power from the grid side
(sum of phases L1, L2, L3)
1)
00.20 Input 1 power W O Instantaneous power at the input 1 - PV1
00.21 Input 1 volt V O DC voltage at the input 1 - PV1
00.22 Input 1 curr A O DC current of the output 1 - PV1
00.23 Input 2 power W O Instantaneous power at the input 2 - PV2/WT
00.24 Input 2 volt V O DC voltage at the input 2 - PV2/WT
00.25 Input 2 curr A O DC current of the output 2 - PV2/WT
00.26 Input 3 power W O Instantaneous power at the input 3
00.27 Input 3 volt V O DC voltage at the input 3
00.28 Input 3 curr A O DC current of the output 3
00.30 Turbine freq. Hz O Frequency of the Turbine generator
00.31 Wind speed m/s O Measured wind speed
00.32 Resistance kΩ O Resistance of an isolation
00.33 Leakage current mA O Measured leakage current
00.34 Digital outputs (1..3) - O Digital outputs state
00.35 Digital inputs (1..5) - O Digital inputs state
00.40 Charger volt. [V] V O Voltage at the input of the charger
00.41 Charger curr. [A] A O DC current at the input of the charger
1 The sign "-" means energy consumption from the electricity grid.
