Chapter 13. Groups of parameters
13.2. Inverter configuration parameters
Parameters from groups 1,2, ... affect the correct operation of the inverter, therefore access to them is
protected by a code, so that an unauthorized person cannot change the parameter settings.
Access code: 123321
GROUP 1 – Grid module
Param.
No.
Name Unit
Access
level
Description
01.01 Work mode - 2 Operation modes:
0 - off grid
1 - on grid
2 - auto on/off grid
3 - test mode
4 - Coolmar mode
5 - off-grid MPPT
01.02 Output volt. V 1 Measured output voltage
01.03 Output freq. Hz 1 Output frequency
01.10 Disconnect volt. V 1 DC input voltage of the generator (AC rectified),
below that value the countdown of the time until the
system disconnects from the grid will start (to reduce
power consumption) - applies to On-grid operation
01.11 Disconnect time s 1 Time after which the system will be disconnected
from the grid (to reduce power consumption) in a
situation where
DC input voltage falls below the level specified in
par. 1.10
01.12 High curr. A 1 Failure high output current threshold
01.13 Limit current A 1 Output current limit
01.20 Autostart volt. V 1 Generator DC input voltage (rectified AC), below
which the system will stop working
01.21 Autostop volt. V 1 DC input PV voltage or rectified AC input generator
voltage, below which the inverter will stop.
01.22 Autostart - 2 Selecting the method for giving the START
command:
0: manual - for entering the START / STOP
command
then corresponds to parameter 1.23
1: automatic
01.23 Enable start - 2 Manually setting the START / STOP command
01.24 Output contact. - 2 Switching on output relays
01.25 Autorestart - 2 On (1) / off (0): automatic reset of failure code r if it
occurs
01.26 Fault reset - 2 Manual reset of the failure, give the following
sequence:
0 → (wait 3 seconds) → 1 → (3 sec.) → 0
01.30 kp curr out - 2 Setting the proportional part of the output current
regulator
01.31 Ki curr out - 2 Setting of the integral part of the output current
regulator
01.32 Udc ref - 2 DC-link reference voltage of the Active-Front-End
(AFE) Converter (AC-DC)
56 PS100 – User manual
