Chapter 13. Groups of parameters
Param.
No.
Name Unit
Access
level
Description
01.33 Kp reg user - 2 Setting the proportional part of the DC-link voltage
regulator
01.34 Ti reg user - Setting the integral part of the DC-link voltage
regulator
01.40 Auto limit curr - 2 Sets how to limit the AFE current above the
referenced Udc threshold
01.41 Modulation - 2 Modulation
01.42 Wind simul. - 2 I/f curve simulation based on Uwej (Uinput)
parameter
01.43 Batt. Work time min 2 Battery operating time
01.44 Alfa min - 2 MPPT parameter
01.45 Alfa max - 2 MPPT parameter
01.46 k rezonans - 2 Parameter from the resonant regulator
GROUP 2 - Input 1: PV1 input
Param.
No.
Name Unit
Access
level
Description
02.01 Uin autostop V 1 Voltage at which input 1 boost converter switches off
02.02 Uref V 2 Reference volatge of the boost converter
02.03 Kp u - 2 Setting the proportional part of the voltage regulator
for the boost converter
02.04 Ti u - 2 Setting of the integral part of the voltage regulator for
the boost converter
02.05 Kp i - 2 Setting the proportional part of the current regulator
for the boost converter
02.06 ti i - 2 Setting of the integral part of the current regulator for
the boost converter
02.07 PWM % 2 Duty cycle for the boost converter
02.08 Max pwm % 2 Max duty cycle for the boost converter
02.09 Dc curr limit A 2 Limit of the input DC current
02.10 Mppt type - 2 Type of MPPT algorithm
02.11 Enable string - 2 Permission for the operation of the input
02.12 Stala filtr user ms 2 Not used
02.13 Stala filtr prad ms 2 Constant of the current filter
02.14 Czas ramp iref ms 2 Current rising time (current slope) for first start-up
02.15 kp Reg UDC1 - 2 Setting of the proportional part of the input current
controller
02.16 Ti Reg UDC1 - 2 Setting of the integral part of the input current
controller
GROUP 3 - Input 2: PV2/WT input
Param.
No.
Name Unit
Access
level
Description
03.01 Uin autostop V 1 Voltage at which input 2 boost converter switches off
03.02 Uref V 2 Reference voltage of the boost converter
PS100 – User manual 57
