Chapter 13. Groups of parameters
Param.
No.
Name Unit
Access
level
Description
03.03 Kp u - 2 Setting the proportional part of the voltage regulator
for the boost converter
03.04 Ti u - 2 Setting of the integral part of the voltage regulator for
the boost converter
03.05 Kp i - 2 Setting the proportional part of the current regulator
for the boost converter
03.06 ti i - 2 Setting of the integral part of the current regulator for
the boost converter
03.07 PWM % 2 Duty cycle for the boost converter
03.08 Max pwm % 2 Max duty cycle for the boost converter
03.09 Dc curr limit A 2 Limit of the input DC current
03.10 Mppt type - 2 Type of MPPT algorithm
03.11 Enable string - 2 Permission for the operation of the input
03.12 Stala filtr user ms 2 Not used
03.13 Sala filtr prad ms 2 Constant of the current filter
03.14 Czas ramp iref ms 2 Current rising time (current slope) for first start-up
03.15 kp Reg UDC1 - 2 Setting of the proportional part of the input current
controller
03.16 Ti Reg UDC1 - 2 Setting of the integral part of the input current
controller
03.30 Prad nom. turb. A 1 Nominal current of the AC generator
03.31 Czest. 1 Hz 1 Frequency value at the 1-st point of the generator
characteristics given as % of the nominal current
03.32 Prad I1 [ % 1 Current value at the 1-st point of the generator
characteristics given as % of the nominal current
... ... - 1 ...
03.61 Czest. 16 Hz 1 Frequency of the 16-th point at the generator’s
characteristic given as % of the nominal current
03.62 Prad I16 % 1 Current value at the 16-th point of the generator
characteristics given as % of the nominal current
GROUP 4 - Input 3
Param.
No.
Name Unit
Access
level
Description
04.01 Uin autostop V 1 Voltage at which input 3 boost converter switches off
04.02 Uref V 2 Reference voltage of the boost converter
04.03 Kp u - 2 Setting the proportional part of the voltage regulator
for the boost converter
04.04 Ti u - 2 Setting of the integral part of the voltage regulator for
the boost converter
04.05 Kp i - 2 Setting the proportional part of the current regulator
for the boost converter
04.06 ti i - 2 Setting of the integral part of the current regulator for
the boost converter
04.07 PWM % 2 Duty cycle for the boost converter
58 PS100 – User manual
