Chapter 3. Specification
19 Algorithm of Maximum Power Point
Tracking
• WT synchronous generator input (AC): characteristic
Igen=f(fgen) defined by user.
• PV input (DC): advanced MPPT global tracking system that
guarantees finding the optimal operating point even with
partially shaded or in series-connected panels.
20 Power consumption in standby mode - W 2
21 Humidity - % 85% for 40
o
C
22 Ambient temperature range -
o
C -10ºC..+40ºC
23 IP protection - - IP65
24 Weight - kg Look at the chapter 3.2 Mechanical
dimensions and weight on page 10.
Devices with battery charger module
25 Nominal voltage of battery Ubat-n V 48 Vdc
26 Nominal charging/discharging
current
Ibat-max A 50 Adc
PS100 – User manual 9
