TYAN FT83-B7119 - Page 88

88
http://www.tyan.com
IPMB_HD1: IPMB Header
Signal
Pin
Pin
Signal
SMB_SDA2
1
2
GND
SMB_SCL2
3
4
NC
USB3_FPIO1: Front USB3.0 Header
Signal
Pin
Pin
Signal
+5V
1
20
KEY
P0_RX_N
2
19
+5V
P0_RX_P
3
18
P1_RX_N
GND
4
17
P1_RX_P
P0_TX_N
5
16
GND
P0_TX_P
6
15
P1_TX_N
GND
7
14
P1_TX_P
P0_N
8
13
GND
P0_P
9
12
P1_N
OC_N
10
11
P1_P
TYPEA_USB3: Vertical Type-A USB3.0 Connector
Signal
Pin
Pin
Signal
SSRX-
5
1
+5V
SSRX+
6
2
USB DATA2-
GND
7
3
USB DATA2+
SSTX-
8
4
GND
SSTX+
9
SSATA_SGPIO1: SSATA SGPIO Pin Header
Signal
Pin
Pin
Signal
SCL
1
2
SSDATA IN
SDA
3
4
SSDATA OUT
GND
5
6
SSLOAD
KEY
7
8
SSCLOCK
P3V3_AUX
9
10
NA
