TYAN FT83-B7119 - Page 89

89
http://www.tyan.com
FPIO_VGA2: Front Panel VGA Header
Signal
Pin
Pin
Signal
GND
1
2
VGA_5V
GND
3
4
HD_VGA_R
GND
5
6
HD_VGA_G
GND
7
8
HD_VGA_B
GND
9
10
HD_VGA_DAT
HD_VGA_HS
11
12
KEY
HD_VGA_CLK
13
14
HD_VGA_VS
J35: Front Fan Connector (Reserved for Barebone Fan Board)
Signal
Pin
Pin
Signal
TACH1
1
2
TACH6
TACH2
3
4
TACH7
TACH3
5
6
TACH8
TACH4
7
8
TACH9
TACH5
9
10
TACH10
GND
11
12
KEY
PWM2
13
14
PWM1
TACH11
15
16
SDA
TACH12
17
18
SCL
V3AUX1
19
20
PWM3
DBG_HD1: TYAN Module Header
Signal
Pin
Pin
Signal
P3V3
1
2
FRAME_N
LAD0
3
4
KEY
LAD1
5
6
PLT_RST_N
LAD2
7
8
GND
LAD3
9
10
CLK_33M
DBG_SERIRQ
11
12
GND
DBG_PRES_N
13
14
VCC3_AUX
TPM_ADDR_MB
15
16
PCH_TPM_PP_EN
