TYAN S7050 - SATA0~SATA5: SATA Connector

http://www.TYAN.com
35
SATA0~SATA5: SATA Connector
7
GND
6
SATA RX DP
5
SATA RX DN
4
GND
3
SATA TX DN
2
SATA TX DP
PIN7 PIN1
1
GND
Connects to the Serial ATA ready drives via
the Serial ATA cable.
SATA1/SATA2:Support SATAII
SATA3/SATA4/SATA5/SATA6:SATAIII
SATA0
SATA1
SATA2
SATA3
SATA4
SATA5
