TYAN S7050 - Recommended Memory Population Table

http://www.TYAN.com
46
Recommended Memory Population Table
To achieve the best performance, TYAN
®
strongly recommended memory installation
configuration as listed below:
Single CPU
Installed
(CPU0 only)
Dual CPU
installed
(CPU0 and CPU1)
Quantity of
memory installed
12346823 4567810121416
CPU0_DIMMD0 √ √ √ √ √ √ √ √ √
CPU0_DIMMD1 √ √ √ √
CPU0_DIMMC0 √ √ √ √ √ √ √ √ √ √ √ √
CPU0_DIMMC1 √ √ √ √
CPU0_DIMMB0 √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
CPU0_DIMMB1 √ √ √ √ √ √
CPU0_DIMMA0 √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
CPU0_DIMMA1 √ √ √ √ √ √
CPU1_DIMMH0 √ √ √ √ √
CPU1_DIMMH1 √
CPU1_DIMMG0 √ √ √ √ √ √ √
CPU1_DIMMG1 √
CPU1_DIMMF0 √ √ √ √ √ √ √ √ √
CPU1_DIMMF1 √ √
CPU1_DIMME0 √ √ √ √ √ √ √ √ √ √ √
CPU1_DIMME1 √ √
1. √ indicates a populated DIMM slot.
2. Paired memory installation for Max performance.
3. Populate the same DIMM type in each channel, specifically
- Use the same DIMM size
- Use the same # of ranks per DIMM
4. Dual-rank DIMMs are recommended over single-rank DIMMs
5. Un-buffered DIMM can offer slightly better performance than registerd DIMM if populating only
a single DIMM per channel
6. We don't suggest other memory installation
