6
Port Q'ty (2) GbE ports
LAN
Controller Intel 82574L
Connector (6) SATA
Controller Intel C602
Speed (2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (black color)
SATA
RAID RAID 0/1/10/5 (Intel Matrix RAID)
Connector (4) SATA connector
Controller Intel C602
Speed 3.0 Gb/s
Storage
SATA
From
(SCU)
RAID RAID 0/1/10 (Intel Matrix RAID)
Chipset Realtek ALC262
Audio
Feature High Definition Audio
USB
(7) USB2.0 ports (4 at rear, 2 at front, 1 type A
onboard) / (2) USB3.0 ports (at rear)
COM
(1) DB-9 COM Connector (at rear, COM1) + (1)
Header (COM2)
Audio LINE_IN, LINE_OUT, MIC_IN connectors
RJ-45 (2) GbE ports
Firewire (2) 2x5-pin headers
Power
SSI 24-pin + 8-pin + 8-pin power connectors / (1) 4
PIN power connector for PCI-E
Front Panel (1) 2x12-pin SSI front panel header
PSMI (1) 1x5-pin header
Input /Output
IPMB (1) 1x4-pin header
Chipset Winbond W83795G
Voltage
Monitors voltage for CPU, memory, chipset &
power supply
Fan Total (7) 4-pin headers
System
Monitoring
Temperature
Monitors temperature for CPU & system
environment
Brand / ROM size AMI / 8MB
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/PXE boot / ACPI 2.0 power management /Power
on mode after power recovery / User-configurable
H/W monitoring / Auto-configurable of hard disk
types
Form Factor SSI EEB
Physical
Dimension
Board Dimension 12"x13" (305x330mm)
Operating
System
OS supported list Please refer to our OS supported list.
FCC (DoC) Class B
Regulation
CE (DoC) Yes
