Ubee DDW3611

Ubee Interactive Using the Upstream Option
Ubee DDW3611 Wireless Cable Modem Gateway Subscriber User Guide • November 2012 25
4.4 Using the Upstream Option
The Upstream screen displays detailed information on the network traffic from the
computer to the remote destination (upstream channels).
Steps
To view upstream information:
1. Click Modem from the main menu.
2. Click Upstream from the left side menu. Field descriptions are listed below the
following screen example.
RxMER
(dB)
Displays the Receiver Modulation Error Ratio used to quantify
the performance of a digital radio receiver in a communications
system using digital modulation.
Correctable Codewords Displays the quantity of codewords which are correctable.
Uncorrectable Codewords Displays the quantity of codewords which are not correctable.
Refresh Updates the screen with the latest information.
Label Description
US-1 to US-4 Numbers the upstream channels.
Channel Type Displays the channel type.
Channel ID Displays the current cable modem upstream channel ID.
Frequency (Hz) Displays the current cable modem upstream frequency in
hertz.
Ranging Status Displays the upstream ranging status.
Label Description
