Using the Forwarding Option Ubee Interactive
50 Ubee DDW3611 Wireless Cable Modem Gateway Subscriber User Guide • November 2012
5.11.4 Viewing Port Maps
Port maps display a list of common applications and the port to which they are assigned.
This option is available from the Forwarding screen.
To view assigned port maps:
1. On the Advanced Gateway – Forwarding screen, click Port Map at the bottom of the
screen.
2. View the application names and pre-assigned port numbers.
Local IP Defines the last digits of the IP address of the local LAN
device to which the forwarding rule applies,. For example, an
Xbox or PC.
Start Port Defines the starting port number listened to by the server host
located in your LAN.
End Port Defines the ending port number listened to by the server host
located in your LAN.
External
Public Interface IP Designates another router on the network to forward data
through. Normally, this field is not modified.
Start Port Defines the port number to start the range of ports to publish
to the Internet.
End Port Defines the port number to end the range of ports published to
Internet.
Note: Be careful when assigning post ranges. Ports within a
range are not usable by other applications that may require
them. We recommend using the same port number as the start
and end of each range.
Protocol Selects the protocol type. Options are UDP, TCPIP, or Both.
Enabled Enables this rule when checked.
View Additional Rules Displays rules 11-20 when selected from the drop-down list, if
they exist. A total of twenty rules are supported.
Apply Saves all screen changes when clicked.
Port Map Shows a list of common applications and their ports.
