Using the DMZ Host Option Ubee Interactive
54 Ubee DDW3611 Wireless Cable Modem Gateway Subscriber User Guide • November 2012
To configure a DMZ host:
1. Connect a PC to an Ethernet port on the DDW3611. Make sure both devices are
powered on and functioning.
2. Connect a Home Gateway (or other device you wish to be in the DMZ) to an Ethernet
port on the DDW3611.
3. Log in to the DDW3611 Web user interface.
4. Go to Tools > Client List. Your PC and other devices are listed.
5. Note the MAC address and IP address of the Home Gateway, VoIP Phone, or other
device to put in the DMZ. For more information, refer to Using the Client List Option on
page 83.
6. Go to Gateway > Static Lease. Enter the MAC address and IP address of a Home
Gateway (or other device you wish to be in the DMZ).
7. Click Apply. For more information, refer to Using the DHCP Static Lease Option on
page 37. A static lease ensures that the device is assigned the same IP address so it
is always available on the network, especially if devices are powered on/off or
disconnected and reconnected.
8. Click Gateway from the main menu.
9. Click DMZ Host from the left side menu. Field descriptions are listed below the screen
example.
10. Enter the IP address you just configured in the Static Lease section.
11. Test the device to ensure Internet access is available and the device is functional. For
example, connect to the Internet from a PC connected to the Home Gateway, or make
calls from a VoIP phone.
The following example shows the DMZ Host set up for a dual Xbox configuration.
