UTD1000L User Manual
26
1. Press key MEASURE to show parameter
measurement menu
2. Press key F1 the screen shall display
measuremen results of all parameters
To measure all customization parameters
automatically under the following steps:
1. Press key MEASURE to show customization
parameter menu
2. Press key F2 the screen shall display
measurement parameters for choice
3. Press key up down/left/right to select type of
parameter being measured marked by
complement color
4. Press key SELECT to confirm the parameter
shall display on the screen automatically with
set maximum of 4 measuremnt parameters
5. Press key F2 to close customization
parameter menu
;
.
;
,
.
/
,
;
,
.
.
Customization Parameter Measurement
Picture 4-17 Measurement of All Parameters
