UNI-T UTD1025CL

UTD1000L User Manual
37
Measure DC Current
To measure DC current lower than 4mA under the
following steps
1. Press key I and the menu shall display
measurement type: DC current, measurement unit
to select different range ( mA A) with the
key F3 the fault range is mA
2. Insert blace table pen into COM banana
socket input port and red one into mA
banana socket input port
3. Connect the red and blace table pen with the
measured point and the screen shall display the
DC current value of the measured point
Picture 5-7 Measurement of DC Current Lower
Than 4mA
To measure DC current lower than 400mA under
the following steps
1. Press key I and the menu shall display
measurement type DC current
2. Press key F3 to set range as mA and the
measurement unit shall be mA
3. Insert blace table pen into COM banana socket
input port and red one into banana socket
input port
:
:
、、
,.
/
.
,
.
:
:.
,
.
.
μA. μA
μA
μA /mA
