UNI-T UTD1025CL User Manual

UTD1000L User Manual
55
Tabel 6-7
Function menu
Trigger Type
Slope
Slope conditions
Next page
Time
Threshold
Back
Set
Slope
﹤
Rise
Fall
Instruction
Set trigger type as slope trigger.
Select a threshold between the rising edge of trigger signal
Select a threshold between the falling edge of trigger signal
Trigger when signal slope between thresholds is bigger than slew
rate set value
Trigger when signal slope between thresholds is smaller
Trigger when signal slope between thresholds equals to slew rate
set value
than slew
rate set value
Second page of slope menu
Set slew rate value and under the menu display conditions to set
pulse width time by left/right key.
Shift low level threshold by up/down key
Shift high level threshold by up/down key
Shift high/low level threshold by up/down key
Back to the first page of slope page
=
----
----
----
Low level
High level
High/low level
﹥
