2. Check trigger type the common signal shall
use edge trigger mode and vedio signal vedio
trigger mode Waveform will display stably only
with correct trigger mode
3. Try to change trigger coupling into high
frequency restriction remove high frequency
noise that interferes trigger
1. Check if trigger method in trigger menu is at
the normal or single gear and if trigger level
exceeds waveform scope If so, center trigger
level or set trigger method as automatic gear.
2. Press key to complete above settings
automatically.
1. Generally it is normal to slow down when
average frequency is over 32
2. Reduce average frequency.
1. It is normal and probably caused by low
horizontal time base gear and could be
improved by increasing horizontal time base to
improve horizontal resolution.
2. Probably the display type is vector lines
between acquisitions points might result in the
echelonment display It can be solved by setting
display type as point display method
:
.
.
,
.
.
,
.
,
.
.
without Display after Pressing Key
RUN/STOP
After Select Opening Average
Acquisition Method Time, Display
Speed Slows Down:
Waveform Displays in Echelonment:
UTD1000L User Manual
