UNI-T UTD1025CL User Manual

88
UTD1000L User Manual
measurement
Cursor
Automatic measurement
Measurement of designated
parameter
Mathematic operation
Store waveform
Record waveform
FFT
Manual mode
Automatic
measurement mode
Window
Acquisition point
Voltage difference between cursors( ),time difference between cursors( )ΔV ΔT
Reciprocal of ΔT 1/ΔT(Hz) ( )
Allowable to display cursor in automatic measurement.
Measurement includes: Peak peak value, amplitude value, maximum value,
minimum value,top value, bottom value, medium value, , average value, mean
square root value, overshoot, preshoot, frequency, period, rise time, fall time,
positive pulse width ( ),,+,-.
negative pulse width duty ratio duty ratio items19
4 types
FFT operation
5 groups of recorded waveform storage
10 groups of interface storage, 20 groups of waveform storage;
screen print
function
Hanning Hamming Biackman Rectangular,, ,
512 points
