Operating Manual for UTD2000/3000
8
Figure 3-9 Trigger of video row
It ha s to che ck if in put sig nal is w ith in ru le sco pe o r
not. Fail refers to out of scope and Pass refers to
within the scope. Pass/Fail signal can be shown b
1. To press[UTILITY] button then press[F2]Enter into
2. Setup of information source: Enter into Pass/Fail
menu then press[F2] to select information source
3. Template setup: To press[F4] Enter into template
setup menu (Template). To press[F2] and[F3] show
in Tem pl ate menu to set hori zo ntal and ver tica l
tolerance scope by multi-function knob, (namely, 1-
200Pixel toward ho
rizontal direction and 1-100Pixel
toward vertical direction.) Please press F4 finall
Return to Pass/Fail menu.
4. Setup of output conditions: To press[F3] to set
output conditions shown in Pass/Fail menu
5. To begin detection: To press[F1] to ope
detection status shown in Pass/Fail menu
The eighth example: Pass/Fail detection
of the rear panel
Rear panel of Pass / Fail output
Pass FailInterface Schematic
