UNI-T UTD3025C User Manual

Usage of operation ke
y
RUN/STOP key is in upper right corner of front
panel of digital storage oscillograph. User ca
n
press the key so that green lamp is on to show
operation status. Red lamp can be on after pressin
g
the k ey to show stop status
.
Figure 2-30 Operation/stop ke
y
A
s shown in above figure, automatic setup is to
simplify operation. Digital storage oscillograph ca
n
adjust vertical deflection coefficient and horizontal
time bas e gear automatically for stable waveform
display on the sc reen ac cording to waveform
amplitude and frequency when user presses AUTO
key. System setup is shown in foll owing form durin
g
automatic setup
:
Automatic setup
Oper ating Man ual fo r UTD 2000/3000
70
