Chapter 2: Instrument Setup
By now, you have been familiar with operation of
vertical control area, horizontal contro l a rea and
trigger system menu for UTD2000/3000 series digital
storage oscillograph p reliminarily. You should be
familiar with setup of digital storage oscillograph b
y
menu operation by introduction shown in previous
chapter. It is suggested to read C hapter 1 if you have
not been familiar with above operation and methods
.
The chapter is mainly to introduce following themes
Set trigger systems of [TRIGGER LEVEL]
,
[MENU], ]50%] and] FORCE]
;
Set sampling mode of [ACQUIRE]
;
It is suggested to read the chapter carefully to know
many measurement functions for UTD2000/3000
and system operation method
.
㧦
Ƶ
Ƶ
Ƶ
Ƶ
Ƶ
Ƶ
Ƶ
Ƶ
Ƶ
Ƶ Set vertical systems of [CH1], ]CH2],] MATH]
,
]REF] , ]OFF] ]VERTICAL POSITION] and
]VERTICAL SCALE]
;
Set horizontal systems of ]MENU] or ]HO
R
MENU], ]HORIZONTAL POSITION] or
[HORIZONTAL SCALE]
;
Set display mode of [DISPLAY]
;
Store and call-out for [STORAGE]
;
Set auxiliary system of [UTILITY]
;
A
utomatic measurement of [MEASURE]
;
Cursor measurement of [CURSOR]
;
Use exec ution buttons of [AUTO] and
[RUN/STOP]
;
