UNI-T UTD3025C User Manual

Oper ating Man ual fo r UTD 2000/3000
3
1
Setup of trigger system
Trigger can determine data acquisition time and
waveform display for digital storage oscillogr aph. It
can convert instable display to meaningful
waveform once correct setup. Digital storage
oscillograph will collect sufficient data to map
waveform in the left side of trigger point firstly. It
will acquire data continuously and synchronousl
y
when waiting for trigger conditions. It also will
acquire sufficient data continuously to map
waveform in the right side of trigger point. Trigger
control area of operation panel of digital storage
oscillograph includes trigger level adjus tm ent knob
and tr igger menu key of [TRIG MENU]
;
5.7-inch oscillograph will set 50% of trigger level i
n
vertical middle point of signal (and realize
UTD2000L /2000EX by press [SET TO ZERO] key)
.
It has to press forced trigger key of [FORCE]
.
Trigger level: Trigger level will set signal voltage
which corresponds to trigger point
.
50%: To set trigger level to vertical point of trigger
signal amplitude
.
FORCE: To produce 1 trigger signal forcefully for
mainly application for normal and single modes
shown in trigger modes
.
TRIG MENU: To trigger and set menu key
.

UNI-T UTD3025C Specifications

General

Bandwidth	25 MHz
Channels	2
Input Voltage Range	400V (DC+AC Peak)
Type	Digital Oscilloscope
Display	5.7-inch TFT LCD
Display Type	Color
Trigger Modes	Edge, Pulse, Video
Interface	USB

Summary

Introduction

General Safety Overview

Overview of safety precautions for operating the instrument correctly and avoiding hazards.

Safety Terms and Symbols

Preface

Chapter 1: User Guideline

Guide to basic operations and front panel functions of the oscillograph.

Chapter 2: Instrument Setup

Detailed setup procedures for various instrument systems and functions.

Chapter 3: Application Example

Chapter 1: User Guideline

General Inspection

Initial checks and inspection of the instrument upon receiving it.

Probe Compensation

Procedure for adjusting probe compensation for accurate measurements.

Automatic Setup of Waveform Display

Chapter 2: Instrument Setup

Setup of Vertical System

Configuration options for the vertical channels, including coupling and bandwidth.

Mathematical Calculation Function

Setup of Horizontal System

Adjusting horizontal time base, position, and view window extension.

Setup of Trigger System

Setting up trigger modes, sources, coupling, and pulse width.

Trigger Control

Setup of Auxiliary Functions

Setup of Display System

Storage and Callout

Cursor Measurement

Using cursors for precise voltage and time measurements on waveforms.

Chapter 3: Application Example

Measurement of Simple Signal

Measuring signal frequency and peak value of a simple unknown signal.

Delay Observation of Sine Wave

Capture of Single Signal

Capturing single aperiodic signals like pulses and burrs using trigger settings.

Reduce Random Noise

Application Cursor Measurement

Application of X-Y Function

Analyzing phase location difference between signals using X-Y display mode.

Trigger of Video Signal

Pass/Fail Detection

Configuring and performing pass/fail tests based on signal tolerance scopes.

Usage of Storage Function

Chapter 4: System Prompt and Troubleshooting
