UNI-T UTD3025C

Operating Manual for UTD2000/3000
5
General inspectio
n
Function inspectio
n
It is suggested to inspect the instrument b
y
following s teps when getting a new UTD2000/3000
series digital storage oscillograph
.
1. To check if there is damage due to transportatio
n
or not
.
Please replace carton or foaming plastic protectio
n
cushion with severe damage ins tantly
.
2. Please inspect fitting details and shown it i
n
“Fittings of UTD2000/3000 series digital S torage
Oscillograph” shown in the manual. You can check
if there are deficient fittings or not by referring to it
.
Please contact UNI-T distributor or local agent if
there are defic ient or damaged fittings
.
3. Please inspect the entire machine and contact UNI-T
distributor or local agent for damaged appearance
,
abnormal operation or failing to pass performance test
.
Please pay attention to packages and report to
transportation department and UNI-T distributor if
machine damage is caused by transportation
.
1. Connect the power suppl
y
You can supply power to the machine and voltage is A
C
100V to AC 240V. Frequency is 45Hz to 440Hz. It has
to press [UTILITY] menu and [F1] for self-correctio
n
after power supply 30 minutes after operation of hot
machine so that digital storage oscillograph operates
under the
best status. As shown in Figure 1 4, please
enter into next page and press [F1] to call out ex-factor
y
setup
.
㧙
UNI-T will arrange maintenance or replacement
.
Please carry out once fast function inspection to
check if the machine operates normally or not
.
Please operate according to foll owing steps
:
