User can move cursor for measurement under
CURSOR mode. There are 3 modes, namely, voltage
time and tracing. V can be measured by pressin
SELECT and COARSE keys on the panel and multi-
purpose knob controller to adjust positions of
cursors respectively during voltage measurement
Similarly, it can be measured if selecting time. Cursor
of digital storage oscillograph can a lso trace signal
variation automatically under tracing mode wit
Remark: For 5.7-inch oscillograp
1. Effect of SELECT key is to select the cursor
2. Effect of COARSE key is to adjust movement speed
of cursor
User can press multi-function knob key to select the
cursor. Movement speed of cursor can also alter
according to rotation speed
1. Voltage/time measurement mode: The first or
secondcursor will appear at the same time. Cursor
position on the screen can be adjusted by multi-
purpose knob controller. User can press SELECT ke
(or multi-function knob key) to select cursor to adjust
Displayed reading is also time or voltage between
orizontal and vertical cursors ca
intersect to become a crossing cursor. Cr ossin
cursor can position on the waveform automatically to
adjust horizontal position of crossing cursor on the
waveform by rotating multi-purpose knob controller
Digital storage oscillograph can also displa
coordinate of cursor point at the same time
3. Measurement value will be dis played in upper
right corner of the screen automatically whe
Operating Manual for UTD2000/3000
6
