UniCarriers 2W1 Series - Main Truck

69
SPECIFICATIONS
MAIN TRUCK - 2W1/2W2
Model code
Item
2W1 2W2
WPXT2W1G60NV/BV WPXT2W1G80NV/BV RPXT2W2G60NV/BV RPXT2W2G80NV/BV
Rated Load Capacity lb (kg) Refer to Truck Data Plate
Truck Weight lb (kg) Refer to Truck Data Plate
Power Type - Electric 24 Volt
Overall Dimensions Head Length in (mm) 34.5 (875) 42.9 (1090)
Chassis Width in (mm) 32 (815) 35.6 (905)
Tires / Wheels
Drive tire-dia. x width in (mm) 10 x 5 (254 x 127)
Caster wheel-dia. x width in (mm) -- 5 x 2.5 (127 x 64)
Load wheel-dia. x width in (mm) 3.25 x 6 (83 x 152)
Lifting Speed
Full Load sec 5.1 6.1 5.1 6.1
Empty sec 3.6
Lowering Speed
Full Load sec 4.8 4.7 4.8 4.7
Empty sec 5.1
Travel Speed
Full Load mph (kph) 3.7 (5.9) 6.6 (10.6) 6.1 (9.8)
Empty mph (kph) 3.7 (5.9) 9.1 (14.6)
*Battery Compartment
Size
Length x Width x Height in (mm)
31.9 x 13.1 x 32 (810 x 330 x 800) 31.9 x 13.25 x 32 (810 x 335 x 815)
Amp Hr Capacity Max (6-hr) Ah 840 840
Weight
Min lb (kg) 900 (410) 900 (410)
Max lb (kg) 1500 (680)
Lead Length Position "B" in (mm) 20 (508)
*Battery compartment size with adjustable retainers - 30.9 x 13.25 x 32 (785 x 335 x 815); w/optional rollers & side gates - 31.1 x 13.25 x 32 (790 x 335 x 815)
