SPECIFICATIONS
AISLE - 2W2
Model code
Item
Single Pallet Double Pallet
36 42 48 84 96
Fork Size Outside Spread in (mm) 27 (685)
Fork Height
Raised Position in (mm) 9.25 (235)
Lowered Position in (mm) 3.25 (82.5)
Individual Fork Width in (mm) 9.25 (235)
Fork Length
Nominal in 36 42 48 84 96
Actual in (mm) 35.7 (910) 41.7 (1060) 47.7 (1210) 83.7 (2125) 95.7 (2430)
Overall Truck Length in (mm) 78.8 (2000) 84.8 (2155) 90.8 (2305) 126.8 (3220) 138.8 (3530)
Face of Forks to Center of
Load Wheel
Forks Raised in (mm) 24.4 (620) 30.4 (770) 36.4 (925) 56.5 (1435)
Forks Lowered in (mm) 28.0 (710) 34.0 (865) 40.0 (1015) 60.1 (1525)
Center of Load Wheel to
Tip of Forks
Forks Raised in (mm) 11.3 (290) 27.2 (690) 39.2 (995)
Forks Lowered in (mm) 7.7 (195) 23.6 (605) 35.6 (905)
Wheelbase
Forks Raised in (mm) 51.6 (1310) 57.6 (1465) 63.6 (1615) 83.5 (2120) 83.5 (2120)
Forks Lowered in (mm) 55.2 (1405) 61.2 (1555) 67.2 (1710) 87.1 (2215) 87.1 (2215)
Grade Clearance Forks Raised w/Pallet % 36.4 32.5 29.4 22.4
Turning Radius in (mm) 68.0 (1730) 73.9 (1875) 79.7 (2025) 99.5 (2530)
*Right Angle Stacking
Aisle
40", 42", 48" Load
Width
in (mm) 78.0 (1980) 84.0 (2130) 90.0 (2285) 128.0 (3230) 140.0 (3540)
*90 Equal Intersecting
Aisle
40" Load Width in (mm) 66.2 (1685) 69.3 (1760) 72.4 (1840) 83.6 (2125) 84.7 (2150)
42" Load Width in (mm) 67.2 (1710) 70.3 (1785) 73.4 (1865) 84.6 (2150) 85.8 (2180)
48" Load Width in (mm) 70.3 (1785) 73.4 (1865) 76.2 (1945) 87.8 (2230) 88.9 (2260)
*Add 6-8" for ease of operation. Includes 1" clearance on each side of load
