Unique CU Series - Page 14

- 8 -
2.2.2 Outdoor Unit Data – Models CU300, CU350, CU400
Model CU300 CU350 CU400
Casing color RAL 7032 RAL 7032 RAL 7032
Dimensions (LxDxH) mm 1080x380x585 1080x380x585 1080x380x585
m
3
/h 3910 3910 4250
Air flow (at high speed)
cfm 2300 2300 2500
Noise Level (see note 1) dbA 46 46 47
Fittings Type Flare Flare Flare
Expansion Device Capillary Tube Capillary Tube Capillary Tube
Axial Fan Diameter/No. mm 500/1 500/1 500/1
Outdoor Fan Motor KW 0.15 0.15 0.15
Motor Capacitor µF/Volt 5/400 5/400 5/400
Speed (High/Low) R.P.M 900/700 900/700 900/700
Face Area m²/ ft² 0.44/4.75 0.44/4.75 0.44/4.75
Tube Diameter Inch 3/8" 3/8" 3/8"
Rows Deep 3 3 4
Coil
Fins Spacing Per Inch 12 12 12
Net Weight Kg. 78 78 96
Notes:
1. Noise level measured at a 4 m. distance in free field.
