8.6 Wiring the Indoor Unit
• Locate the terminal box cover according to the following figures.
• Remove the indoor unit side cover.
• Connect the wires to the terminals, in accordance with the color coding and the
suitable wiring diagrams.
• Make sure that all connections are properly inserted and fastened.
• Make sure that all screws and wires are properly fastened. Loose wires or connections
can cause damage and present a fire hazard!
• Reassemble the side cover.
8.6.1 Indoor Unit Terminal Box CUE-150A…800A and 150C…1000C
