- 25 -
3.1.2 Technical Data
Model CUP350 CUP400 CUP450 CUP480 CUP500
G E N E R A L
LxDxH mm 1080x1100x850 1080x1100x850 1200x1100x850 1200x1100x850 1200x1150x1030
A mm 265 265 265 265 295
B mm 305 305 305 340 335
E mm 380 380 380 380 460
Dimensions
F mm 555 655 755 755 785
Condensate Lines - Drain Ф-mm (in) 19 (3/4") 19 (3/4") 19 (3/4") 19 (3/4") 19 (3/4")
Noise Level (see note 1) dbA 46 47 47 48 50
Net Weight Kg. 135 151 167 175 189
C O N D E N S E R S I D E
m
3
/h 3910 4250 4760 5100 5780
Air flow (at high speed)
cfm 2300 2500 2800 3000 3400
Axial Fan Diameter mm 500 500 500 500 550
Number of Fans 1 1 1 1 1
Speed (High/Low) R.P.M 900/700 900/700 900/700 900/700 900/700
Face Area m²/ ft² 0.44/4.75 0.44/4.75 0.51/5.5 0.72/7.8 0.72/7.8
Tube Diameter Inch 3/8" 3/8" 3/8" 3/8" 3/8"
Rows Deep 3 4 4 3 4
Condenser Coil
Fins Spacing Per Inch 12 12 12 12 12
E V A P O R A T O R S I D E
m
3
/h 1870 2295 2550 2720 2975
Air Flow (at High speed)
cfm 1100 1350 1500 1600 1750
High Fan Speed R.P.M 900 900 900 900 900
Number of Speeds 3 3 3 3 3
Net Static Pressure (see note 2) mm H
2
O 7 6 6 6 13
Number of Fans 1 1 1 1 1
Fan Type and Model Centrifugal DD9-9-245W DD9-9-370W DD9-9-370W DD9-10-370W DD10-10-550W
Face Area m²/ ft² 0.20/2.16 0.24/2.59 0.27/2.92 0.27/2.92 0.34/3.67
Tube Diameter Inch 3/8" 3/8" 3/8" 3/8" 3/8"
Rows Deep 4 4 4 5 4
Evaporator Coil
Fins Spacing Per Inch 12 12 12 12 12
Notes:
1. Noise level measured at a 4 m. distance in free field.
2. Net static pressure available at fan discharge at nominal capacity.
