- 26 -
3.2 Packages CUP600…CUP800
3.2.1 Performance
Notes:
1. Nominal cooling capacity based on indoor air temp.
27ºC db/19.5ºC wb and outdoor air temp. 35ºC db/24º wb.
2. Nominal heating capacity based on indoor air temp.
21ºC db and outdoor air temp. 7.5ºC db/6.1ºC wb.
3. Operating current measured at the most loaded phase.
R22
Model CUP600 CUP700 CUP800
Watt 17585 21102 24619
Cooling capacity
Btu/h 60000 72000 84000
Watt 17790 21249 24912
Heating capacity
Btu/h 60700 72500 85000
Power Consumption - cooling Watt 6520 8000 8790
Power Consumption - Heating Watt 6130 7100 8500
Operating Current (cooling/Heating) Amp 14.2/14 18/17.6 20/19.3
E.E.R - Energy Efficiency Ratio Cooling 9.2 9.0 9.5
C.O.P - Coefficient Of Performance Heating 2.9 3.0 2.9
Moisture Removal Lit/h 7.8 8.8 10.2
Power Supply V/Ph/Hz 400V, 3Ph, 50Hz
Time Delay Fuse Amp. 3xC-20 3xC-25 3xC-32
R407C
Model CUP600 CUP700 CUP800
Watt 17291 20515 24180
Cooling capacity
Btu/h 59000 70000 82500
Watt 17410 20650 24200
Heating capacity
Btu/h 59400 70500 82570
Power Consumption - cooling Watt 6480 7920 8730
Power Consumption - Heating Watt 6100 7300 8500
Operating Current (cooling/Heating) Amp 13.8/13.0 17.7/17.3 18.8/18.2
E.E.R - Energy Efficiency Ratio Cooling 9.1 8.83 9.45
C.O.P - Coefficient Of Performance Heating 2.85 2.82 2.85
Moisture Removal Lit/h 7.8 8.8 10.2
Power Supply V/Ph/Hz 400V, 3Ph, 50Hz
Time Delay Fuse Amp. 3xC-20 3xC-25 3xC-32
