- 24 -
3.1 Packages CUP350…CUP500
3.1.1 Performance
Notes:
1. Nominal cooling capacity based on indoor air temp.
27ºC db/19.5ºC wb and outdoor air temp. 35ºC db/24º wb.
2. Nominal heating capacity based on indoor air temp.
21ºC db and outdoor air temp. 7.5ºC db/6.1ºC wb.
3. Operating current models CUP350 and CUP400: for 230V, 1Ph.
Operating current models CUP450…CUP500 measured at the most loaded phase.
R407C
Model CUP350 CUP400 CUP450 CUP480 CUP500
Watt 9730 11137 12896 13745 14390
Cooling capacity
Btu/h 33200 38000 44000 46900 49100
Watt 9710 10980 12820 13700 14920
Heating capacity
Btu/h 33130 37500 43740 46750 50910
Power Consumption - cooling Watt 3460 4380 5000 5300 5700
Power Consumption - Heating Watt 3195 4070 4700 4750 5250
Operating Current (cooling/Heating) Amp 16.3/15.1 20.7/19.2 8.3/7.8 8.8/7.9 9.4
E.E.R - Energy Efficiency Ratio Cooling 9.76 8.67 8.8 8.84 8.6
C.O.P - Coefficient Of Performance Heating 3.0 2.7 2.72 2.88 2.84
Moisture Removal Lit/h 4.2 4.8 5.9 6.7 6.9
Power Supply V/Ph/Hz
230V, 1Ph, 50Hz
or 400V, 3Ph, 50Hz
400V, 3Ph, 50Hz
Time Delay Fuse Amp. C-20 or 3xC-10 C-25 or 3xC-16 3xC-16 3xC-16 3xC-16
R22
Model CUP350 CUP400 CUP450 CUP480 CUP500
Watt 9965 11284 13189 14009 14654
Cooling capacity
Btu/h 34000 38500 45000 47800 50000
Watt 10111 11430 13335 14185 15533
Heating capacity
Btu/h 34500 39000 45500 48400 53000
Power Consumption - cooling Watt 3470 4410 5060 5330 5730
Power Consumption - Heating Watt 3260 4155 4760 4770 5350
Operating Current (cooling/Heating) Amp 17.6/16.6 20.8/19.6 9.2/8.4 11.2/10.4 12.1/11.3
E.E.R - Energy Efficiency Ratio Cooling 9.8 8.7 8.9 9.0 8.7
C.O.P - Coefficient Of Performance Heating 3.1 2.8 2.8 3.0 2.9
Moisture Removal Lit/h 4.2 4.8 5.9 6.7 6.9
Power Supply V/Ph/Hz
230V, 1Ph, 50Hz
or 400V, 3Ph, 50Hz
400V, 3Ph, 50Hz
Time Delay Fuse Amp. C-20 or 3xC-10 C-25 or 3xC-16 3xC-16 3xC-16 3xC-16
