- 27 -
3.2.2 Technical Data
Model CUP600 CUP700 CUP800
G E N E R A L
LxDxH mm 1650x1150x1030 1650x1350x1130 1650x1350x1130
A mm 295 345 345
B mm 335 400 400
E mm 460 510 510
Dimensions
F mm 885 915 1058
Condensate Lines - Drain Ф-mm (in) 22 (7/8") 22 (7/8") 22 (7/8")
Noise Level (see note 1) dbA 52 54 54
Net Weight Kg. 260 280 305
C O N D E N S E R S I D E
m
3
/h 8500 10200 11900
Air flow (at high speed)
cfm 5000 6000 7000
Axial Fan Diameter mm 500 550 550
Number of Fans 2 2 2
Speed (High/Low) R.P.M 900/700 900/700 900/700
Face Area m²/ ft² 0.85/9.18 0.85/9.18 0.98/10.58
Tube Diameter Inch 3/8" 3/8" 3/8"
Rows Deep 3 4 4
Condenser Coil
Fins Spacing Per Inch 12 12
12
E V A P O R A T O R S I D E
m
3
/h 3400 4080 4760
Air Flow (at High speed)
cfm 2000 2400 2800
High Fan Speed R.P.M 900 900 900
Number of Speeds 3 3 3
Net Static Pressure (see note 2) mm H
2
O 13 18 8
Number of Fans 1 1 1
Fan Type and Model Centrifugal DD10-10-550W DD12-12-550W DD12-12-550W
Face Area m²/ ft² 0.39/4.21 0.45/4.86 0.52/5.62
Tube Diameter Inch 3/8" 3/8" 3/8"
Rows Deep 4 4 4
Evaporator Coil
Fins Spacing Per Inch 12 12 12
Notes:
1. Noise level measured at a 4 m. distance in free field.
2. Net static pressure available at fan discharge at nominal capacity.
