2.3.2 Outdoor Unit Data – Models CU450, CU480, CU500
Model CU450 CU480 CU500
Casing color RAL 7032 RAL 7032 RAL 7032
Dimensions (LxDxH) mm 1150x415x661 1150x415x661 1150x415x661
m
3
/h 4760 5100 5780
Air flow (at high speed)
cfm 2800 3000 3400
Noise Level (see note 1) dbA 47 48 50
Fittings Type Flare Flare Flare
Expansion Device Capillary Tube Capillary Tube Capillary Tube
Axial Fan Diameter/No. mm 500/1 500/1 550/1
Outdoor Fan Motor KW 0.15 0.15 0.37
Motor Capacitor µF/Volt 5/400 5/400 10/400
Speed (High/Low) R.P.M 900/700 900/700 900/700
Face Area m²/ ft² 0.51/5.5 0.72/7.8 0.72/7.8
Tube Diameter Inch 3/8" 3/8" 3/8"
Rows Deep 4 3 4
Coil
Fins Spacing Per Inch 12 12 12
Net Weight Kg. 100 105 115
Notes:
1. Noise level measured at a 4 m. distance in free field.
