2.5.2 Outdoor Unit Data – Models CU1000, CU1200, CU1400
Model CU1000 CU1200 CU1400
Casing color RAL 7032 RAL 7032 RAL 7032
Dimensions (LxDxH) mm
1700x830x1000 1700x830x1000 1700x830x1150
m
3
/h
16150 15300 15300
Air flow (at high speed)
cfm
9500 9000 9000
Noise Level (see note 1) dbA
75 75 75
Fittings Type Flare Soldering Soldering
Expansion Device Expansion valve Expansion valve Expansion valve
Axial Fan Diameter/No. mm 630/2 630/2 630/2
Outdoor Fan Motor KW 2x0.66 2x0.66 2x0.66
Motor Capacitor µF/Volt N/A N/A N/A
Speed (High/Low) R.P.M 900/700 900/700 900/700
Face Area m²/ ft² 1.82/19.7 1.82/19.7 1.82/19.7
Tube Diameter Inch 3/8" 3/8" 3/8"
Rows Deep 2 3 4
Coil
Fins Spacing Per Inch 12 12 12
Net Weight Kg. 250 283 305
Notes:
1. Noise level measured at a 4 m. distance in free field.
