- 29 -
3.3.2 Technical Data
Model CUP1000 CUP1200 CUP1400
G E N E R A L
LxDxH mm 1700x1500x1150 1700x1500x1150 1700x1500x1250
A mm 295 345 345
B mm 335 400 400
C mm 1010 1114 1114
E mm 460 533 635
Dimensions
F mm 1335 1435 1435
Condensate Lines - Drain Ф-mm (in)
28 (1
⅛") 28 (1⅛") 28 (1⅛")
Noise Level (see note 1) dbA 75 75 75
Net Weight Kg. 410 460 505
C O N D E N S E R S I D E
m
3
/h
16150 15300 15300
Air flow (at high speed)
cfm
9500 9000 9000
Axial Fan Diameter mm 630 630 630
Number of Fans 2 2 2
Speed (High/Low) R.P.M 900/700 900/700 900/700
Face Area m²/ ft² 1.84/19.87 1.86/20.1 1.87/20.2
Tube Diameter Inch 3/8" 3/8" 3/8"
Rows Deep 2 3 4
Condenser Coil
Fins Spacing Per Inch 12 12 12
E V A P O R A T O R S I D E
m
3
/h 5440 6800 8160
Air Flow (at High speed)
cfm 3200 4000 4800
High Fan Speed R.P.M 900 900 900
Number of Speeds 3 3 3
Net Static Pressure (see note 2) mm H
2
O 14 20 18
Number of Fans 2 2 2
Fan Type and Model Centrifugal DD10-10-370W DD12-12-550W DD12-12-550W
Face Area m²/ ft² 0.59/6.37 0.75/8.1 0.89/9.61
Tube Diameter Inch 3/8" 3/8" 3/8"
Rows Deep 4 4 4
Evaporator Coil
Fins Spacing Per Inch 12 12 12
Notes:
1. Noise level measured at a 4 m. distance in free field.
2. Net static pressure available at fan discharge at nominal capacity.
