Unique CU Series - Page 85

- 79 -
CU150, CU200, CU250 (Outdoor Unit Electrical Components)
Part No.
CU250 CU200
CU150
Part Description
No. in
Figure
0404O500 0404O500 0404O500 Axial Fan 1a
03015010 03015010 03015010 Fan motor 2
100305MF 100305MF 100305MF Fan motor capacitor 4
100345MF 100335MF 100325MF Compressor capacitor 5
1001G7LO 1001G7LO 1001G7LO Contactor 7
CU300, CU350, CU400 (Outdoor Unit Electrical Components)
Part No.
CU400 CU350
CU300
Part Description
No. in
Figure
0404O500 0404O500 0404O500 Axial Fan 1a
03015010 03015010 03015010 Fan motor 2
1505K500 1505K500 1505K500 Fan protector 3
100305MF 100305MF 100305MF Fan motor capacitor 4
100340MF 100340MF 100345MF Compressor capacitor 5
1001G7LO 1001G7LO 1001G7LO Contactor 1Ph 6
1001CI13 1001CI09 1001CI09 Contactor 3Ph 7
CU450, CU480, CU500 (Outdoor Unit Electrical Components)
Part No.
CU500 CU480
CU450
Part Description
No. in
Figure
0404O500 0404O500 0404O500 Axial Fan 1a
03014011 03015010 03015010 Fan motor 2
1505K500 1505K500 1505K500 Fan protector 3
100310MF 100305MF 100305MF Fan motor capacitor 4
1001CI15 1001CI12 1001CI12 Contactor 6
CU600, CU700, CU800 (Outdoor Unit Electrical Components)
Part No.
CU800 CU700
CU600
Part Description
No. in
Figure
0404O550 0404O550 0404O500 Axial Fan 1a
03014011 03014011 03015010 Fan motor 2
1505K500 1505K500 1505K500 Fan protector 3
100310MF 100310MF 100310MF Fan motor capacitor 4
1001Ci25 1001Ci20 1001Ci20 Contactor 6
1001G7LO 1001G7LO 1001G7LO Normally Open Relay 8
1001RSTC 1001RSTC 1001RSTC RST Controller (for "Scroll" only) 9
