Universal Robots UR3e PolyScope X - Control Box Clearance

5.5. Control Box Clearance
Description The flow of hot air in the Control Box can result in equipment malfunction.
The Control Box requires a minimum clearance of 50mm on each side for sufficient
cool airflow. The recommended Control Box clearance is 200mm.
WARNING
A wet Control Box can cause fatal injury.
•
Make sure the Control Box and cables do not come into
contact with liquids.
•
Place the Control Box (IP44) in an environment suited for the
IP rating.
User Manual 43 UR3e PolyScope X
5.Assembly
Copyright © 2009–2024 by UniversalRobotsA/S. All rights reserved.
