Uponor Smatrix Base Thermostat Dig T-146
The thermostat shows the ambient or set temperature
on the display. Temperature settings are adjusted using
the +/- buttons on the front.
Main characteristics:
• Backlit display, dims after 10 seconds of inactivity.
• Displays Celsius or Fahrenheit.
• Calibration of displayed room temperature.
• Heating/cooling demand indication on display.
• Displays software version during power up
sequence.
• Setpoint range is 5 – 35 °C (maximum and
minimum setting may be limited by other system
settings).
• Room temperature regulation with use of optional
external temperature sensors.
• Displays optional temperature sensor values
if sensors are connected and relevant room
temperature regulation is activated.
• Switch between Comfort and ECO mode with
optional timer.
• Adjust ECO setback value.
Components of the thermostat:
The illustration below shows the thermostat and its
components.
C
Item Description
A Uponor Smatrix Base Thermostat Dig T-146
B Wall bracket
C Connection terminals
D Mounting material
Uponor Smatrix Base Thermostat Standard T-145
The thermostat temperature settings are adjusted using
the dial. The 21 °C position is marked on the dial.
Main characteristics:
• Adjust temperature setpoint with large dial.
• Setpoint range is 5 – 35 °C (maximum and
minimum setting may be limited by other system
settings).
• Printed scale on the dial.
• LED in lower right corner indicating, for about
60 seconds, whether a heating or cooling demand
exists.
• Enable or disable Comfort/ECO scheduling for the
room with a dip switch on the back.
Components of the thermostat:
The illustration below shows the thermostat and its
components.
