Upright NX15 Service & Parts Manual

Page 2-14
Operation and Specifications 2.7 - Specifications
MX15/19
2.7 S
PECIFICATIONS
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
The MX Series meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999
ITEM MX15 MX19
Platform Size (Inside minimum)
Standard w/Deck 22.5 in. x 100 in. (.57 m x 2.54 m) 22.5 in. x 100 in. (.57 m x 2.54 m)
Maximum Platform Capacity
Standard w/Deck Extension 550 lbs. (250 kg) 500 lbs. (250 kg)
Maximum Number of Occupants
Standard w/Deck Extension 2 People 2 People
on Extension 1 Person 1 Person
Height
Working Height 21 ft. (6.3 m) 25 ft. (7.6 m)
Maximum Platform Height 15 ft. (4.5 m) 19 ft. (5.8 m)
Maximum Drivable Height 15 ft. (4.5 m) 19 ft. (5.8 m)
Dimensions
Weight 2300 lbs. (890 kg) 3100 lbs. (1406kg)
Overall Width 30 in. (760 mm) 30 in. (760 mm)
Overall Height (Lowered) 74.9 in. (1.89 m) 79.25 in. (2.01 m)
Overall Length (Deck in) 68.75 in. (1.75 m) 68.75 in. (1.75 m)
Drivable Height 15 ft. (4.5 m) 19 ft. (5.8 m)
Drive Speed
Platform Lowered 2.3 mph (3.7 km/h) 2.3 mph (3.7 km/h)
Platform Raised .62 mph (1 km/h) .62 mph (1 km/h)
Energy Source
24V battery pack (4-220 ampere hour,
6 Volt batteries, min. wt. 62 lbs. (28
kg) each), 4 HP DC electric motor
24V battery pack (4-220 ampere hour,
6 Volt batteries, min. wt. 62 lbs. (28
kg) each), 4 HP DC electric motor
System Voltage 24 VDC 24 VDC
Battery Charger 20 AMP, 120 VAC 60 Hz, Automatic 20 AMP, 120 VAC 60 Hz, Automatic
Hydraulic Tank Capacity 3.4 gal (12.9 L) 3.4 gal (12.9 L)
Maximum Hydraulic System Pressure 2500 psi (172 Bar) 3500 psi (241 Bar)
Lift System One Single Stage Lift Cylinder One Single Stage Lift Cylinder
Drive Control Motor Control Motor Control
Control System
Control Handle with Interlock Switch,
Rotary Drive/Lift Switch, and Red
Mushroom Emergency Stop Switch
Control Handle with Interlock Switch,
Rotary Drive/Lift Switch, and Red
Mushroom Emergency Stop Switch
Drive System Dual Front Wheel Hydraulic Motors Dual Front Wheel Hydraulic Motors
Tires
12 in. (30.5 cm) diameter solid rubber,
Non-marking
12 in. (30.5 cm) diameter solid rubber,
Non-marking
Parking Brake
Dual,SpringApplied,Hydraulic
Release
Dual, Spring Applied, Hydraulic
Release
Turning Radius (inside) 1 in. (25 mm) Inside 1 in. (25 mm) Inside
Maximum Gradeability 25% (14°) 25% (14°)
Wheel Base 48.5 in. (1.23 m) 48.5 in. (1.23 m)
Guardrails 39 in. (1.02 m 39 in. (1.02 m)
Toeboard 6 in. (152 mm) 6 in. (152 mm)
