Upright NX15 Service & Parts Manual

Page 6-2
Illustrated Parts Breakdown -6.1-Introduction
MX15/19
Final Assembly, MX15
065600-020
ITEM PART DESCRIPTION QTY.
1 065601-020 BASIC ASSY 1
3 063944-001 CHARGER 1
4 066490-020 SWITCH ROLLER ASSY 1
5 011248-003 NUTHEX ESNA 10-24 2
6 011240-003 WASHER #10 STD FLAT 4
7 065610-020 CONTROLLER ASSEMBLY 1
8 013965-005 SCREW HHC 10-24 X 5/8 2
9 015796-000 BATTERY 6 V 4
015796-001 BATTERY, DRY
10 065614-000 EXTENSION DECK 1
11 065603-004 PLATFORM/GUARDRAIL ASSY 1
12 066489-000 SWITCH BRACKET 1
14 065611-021 HYDRAULIC HOSE KIT / INST. 1
15 065615-023 HYDRAULIC SCHEMATIC REF
16 065616-024 ELECTRICAL SCHEMATIC REF
17 110020-002 MX SPECIFICATION SHEET REF
18 065612-030 LABEL KIT / INSTALLATION 1
19 065609-020 CONTROL CABLE ASSY 1
20 065943-002 WIRE HARNESS ASSY 1
21 065746-000 CONTROLLER GUIDE 1
20 065943-002 WIRE HARNESS ASSY 1
21 065746-000 CONTROLLER GUIDE 1
22 062125-052 CABLE ASSY X 52 1
23 064195-019 CABLE ASSY X 19 1
24 064195-104 CABLE ASSY X 104 1
25 064195-014 CABLE ASSY X 014 2
26 062125-005 CABLE ASSY X 14 1
27 101182-001 CABLE ASSY W/ CONNECTOR 1
28 062125-003 CABLE ASSY X 24 1
29 101182-002 CABLE ASSY W/ CONNECTOR 1
30 010154-001 COVER BATTERY TERMINAL 10
31 029601-039 CONN RING 5/16 10-12 3
32 067336-000 PLUG ASSY M 110Vac 2
33 066307-015 LADDER WELDMENT 1
34 063497-025 PLUG, BYPASS WIRE ASS’Y 1
35 067336-001 PLUG ASSY FM 110Vac 1
37 029435-099 WIRE AWG 14 GA 3 CONN. 37
38 065942-002 CABLE ASSY VALVE BLOCK 1
39 065980-002 WHEEL COVER ASSY 1
40 067340-001 WIRE ASS’Y LOWER CONTROLS 1
41 029945-020 LEVEL SENSOR WIRE ASSY 1
44 029601-021 CONN RING 3/8 10-12 1
45 013283-002 CABLE MOUNT 2
46 011252-012 SCREW HHCS1/4-20 X 11/2 2
49 011252-006 SCREW HHC 1/4-20UNC X 3/4 6
50 011238-004 WASHER 1/4 LOCK 2
51 011240-004 WASHER 1/4 STD FLAT 8
52 011248-004 NUTHEX ESNA 1/4-20UNC 12
53 066505-000 BRACKET 1
54 065682-000 SPACER 1
56 011254-008 SCREW HHC 3/8-16 UNC X 14
57 011240-006 WASHER 3/8 STD FLAT 8
58 011248-006 NUTHEX ESNA 3/8-16 UNC 4
64 065798-000 MOUNTING PLATE BALLAST 1
65 011252-048 SCREW HHC 1/4-20 UNC X 64
66 019775-017 BAR 3
ITEM PART DESCRIPTION QTY.
060569-004
