Basic Operation
3-39
3
9 Enter "Scan to SMB" in "Name" and click Finish.
NOTE: In Windows XP or Windows Vista, follow the procedure below to set the port.
1 In Windows XP, from Start button on the Windows, select Control Panel, and then Windows Firewall.
In Windows Vista, from Start button on the Windows, select Control Panel, Security, and then Turn
Windows Firewall on or off.
If the User Account Control dialog box appears, click the Continue button.
2 Click the Exceptions tab and then the Add port... button.
3 Specify Add a Port settings.
Enter any name in "Name" (example: Scan to SMB). This will be the name of the new port. Enter "445" in "Port
Number". Select TCP for "Protocol".
4 Click the OK button to close the Add a Port dialog box.
In Windows 8, follow the procedure below to set the port.
1 In charms on Desktop, click Settings, Control Panel, System and Security, and then Windows Firewall.
If the User Account Control dialog box appears, click the Continue button.
2 Configure the settings, refer to Configuring Windows Firewall (for Windows 7) on 3-36.
