8.11 Fieldbus Data-Mapping (Control panel: Menu PAR -> P10)
P9.9
Analog output E2
signal selection
0
14 0 479
As parameter P9.1, hidden
until an option board is con-
nected
P9.10
Analog output E2
minimum
0
1 0 482
As parameter P9.2, hidden
until an option board is con-
nected
P9.11
Analog output E2
scaling
0,0 1000,0 % 100,0 483
As parameter P9.3, hidden
until an option board is con-
nected
P9.12
Analog output E2
filter time
0,00 10,00 s 0,10 480
As parameter P9.4, hidden
until an option board is con-
nected
Code Parameter Min Max Unit Default ID Note
P10.1
FB Data Output 1
selection
0 Varies 0 852
0 = Frequency reference
1 = Output reference
2 = Motor speed
3 = Motor current
4 = Motor voltage
5 = Motor torque
6 = Motor power
7 = DC link voltage
8 = Active fault code
9 = Analogue AI1
10 = Analogue AI2
11 = Digital input state
12 = PID feedback value
13 = PID setpoint
14 = Pulse train /
encoder input (%)
15 = Pulse train /
encoder pulse()
16 = AIE1
P10.2
FB Data Output 2
selection
0
Varies 1 853 Variable mapped on PD2
P10.3
FB Data Output 3
selection
0
Varies 2 854 Variable mapped on PD3
P10.4
FB Data Output 4
selection
0
Varies 4 855 Variable mapped on PD4
Table 8.11: Fieldbus Data-Mapping
Code Parameter Min Max Unit Default ID Selections
Table 8.10: Analogue outputs
