vacon parameters
8
8.10 Analogue outputs (Control panel: Menu PAR -> P9)
Code Parameter Min Max Unit Default ID Selections
P9.1
Analog output
signal selection
0 14 1 307
0 = Not used
1 = Output freq. (0-f
max
)
2 = Output current (0-I
nMotor
)
3 = Motor torque (0-T
nMotor
)
4 = PID output (0 - 100%)
5 = Freq. refer. (0-f
max
)
6 = Motor speed (0-n
max
)
7 = Motor power (0-P
nMotor
)
8 = Motor Voltage (0-U
nMotor
)
9 = DC-link Voltage
(0 - 1000 V)
10 = Process Data In1
(0 - 10000)
11 = Process Data In2
(0 - 10000)
12 = Process Data In3
(0 - 10000)
13 = Process Data In4
(0 - 10000)
14 = Test 100%
P9.2
Analog output
minimum
0 1 0 310
0 = 0 V / 0 mA
1 = 2 V / 4 mA
P9.3
Analog output
scaling
0,0 1000,0 % 100,0 311 Scaling factor
P9.4
Analog output fil-
ter time
0,00
10,00 s 0,10 308 Filter time
P9.5
Analog output E1
signal selection
0
14 0 472
As parameter P9.1, hidden
until an option board is con-
nected
P9.6
Analog output E1
minimum
0
1 0 475
As parameter P9.2, hidden
until an option board is con-
nected
P9.7
Analog output E1
scaling
0,0 1000,0 % 100,0 476
As parameter P9.3, hidden
until an option board is con-
nected
P9.8
Analog output E1
filter time
0,00 10,00 s 0,10 473
As parameter P9.4, hidden
until an option board is con-
nected
Table 8.10: Analogue outputs
